Single Mode Fiber Array

     Single-mode Fiber Arrays are widely used in communications, optical sensors, medical devices and scientific instruments to efficiently transmit signals across and between connected optical devices. Our single-mode Fiber Array is a product designed for high-precision applications. It covers a wavelength range from 320nm to 2200nm and is suitable for a variety of optical applications. Moreover, this single-mode fiber array is highly accurate, with a linear array fiber alignment accuracy of ±0.3um, which is especially suitable for small-mode field fiber arrays. The use of our single-mode fiber arrays can greatly reduce the losses in optical waveguide devices and optical coupling alignment, enabling more accurate optical measurement and transmission.


Single Mode Fiber Array    to find Reful
      Complete           variety
      Reliable             quality
Professional           team
On time
Product parameter














Fiber arrangement shape





Pitch of line Fiber array






Pitch of 2D Fiber array






Length of Fiber array






Length of Fiber array






Number of Fiber array



Dark Fiber Rate ≤ 1%,

Accuracy ± 3um


Number of Fiber array



Dark fiber ratio 0,

Accuracy ± 1um

Array end service temperature without vacuum requirement




Operating temperature of array end with vacuum requirement





Air leakage rate




Vibration resistance frequency range





Three-directional sine


Optical axis parallelism





Fiber array grinding angle







                       Product shooting



320nm Single mode fiber array

Applicable wavelength:320~430nm

Mode field diameter:2.4μm


405nm Single mode fiber array

Applicable wavelength:400~680nm

Mode field diameter:3.3μm


450nm Single mode fiber array

Applicable wavelength:450~680nm

Mode field diameter:3.5μm


630nm Single mode fiber array

Applicable wavelength:680~86nm

Mode field diameter:4.2μm


780nm Single mode fiber array

Applicable wavelength:780~970nm

Mode field diameter:5μm


980nm Single mode fiber array

Applicable wavelength:980~1550nm

Mode field diameter:6.6μm


1550nm Single mode fiber array

Applicable wavelength:1440~1600nm

Mode field diameter:10.1μm


Large NA single mode fiber array

Applicable wavelength:1100~1600nm

Mode field diameter:4.8μm


Large NA single mode fiber array

Applicable wavelength:900~1600nm

Mode field diameter:4.1μm
