2D High-Speed APD Detector Array

     Combined with high precision 2D fiber optic array, our company introduces 2D High Speed Detector Array. The product has accurate positioning function, which can detect the surface array of the detected object and output high precision position information. It is suitable for the detection, monitoring and imaging of high-speed moving objects and high-speed reaction processes.

    This product separates the 2D fiber optic array probe from the electric control part, the probe has the advantages of small size, anti-radiation, anti-electromagnetic interference, high and low temperature resistance. It has a unique advantage for the detection of narrow space in harsh environment.

     The product can also provide bias power supply and transimpedance amplifier (preamplifier), and is equipped with the main amplifier, waveform discrimination and other circuits according to demand.

 2D High-speed APD Detector Array to find Reful
   Complete            variety
      Reliable             quality
Professional            team
On time
Product parameters
        Detector array technical parameters
 Wavelength:                                 800-1700nm
 Active diameter:                       50μm
Responsivity:                  0.9A/W(λ=1550nm,φe=1μW,M=1)
Multiplication gain:              10
Bandwidth:                  50MHz (-3dB)
Dark Current:                 0.8nA
Total capacitance:              0.7pF
Reverse breakdown voltage:  44V
Peak Power:                    300μW
 Fiber Coupling:                  FC/PC
Product characteristics
High sensitivity
High sensitivity
Low dark current, high response, and higher detection sensitivity. Suitable for laser ranging of high-speed moving objects, free-space optical communication, infrared online monitoring, imaging and other applications.

High precision
High positioning accuracy

The front end of the detector is equipped with a high-precision 2D fiber optic array, which can detect the surface array of the object and output high-precision position information.

Small space
Suitable for detecting small spaces

Fiber optic array probe and electronic control part of the separation, the probe has a small size, anti-radiation, anti-electromagnetic interference, the advantages of high and low temperature resistance. To the harsh environment of the narrow space detection has a unique advantage.

Product shooting
